Griggio T 270 SPINDLE MOULDER id:4722

Specyfikacja produktu

T 270 SPINDLE MOULDER

Technical data:
- Working table sizes 1200x730 mm.
- Working shaft:
* Useful height with dia. 40 mm. 240 mm.
* Useful height with dia. 50 mm. 270 mm.
* Stroke 210 mm.
* Rotation speed 3000-4500-6000
  8000-10000 r.p.m.
- Max. sizes of the tool reentering under
the working table 320x190 mm.
- Selfbraking motor power 10" 7,5 hp (5,5 kw)
- Net weight 670 kg.
- Noise level according to CE 848-1 75,3 db (A)


The machine is equipped with:
Guard fence for adjustable shaft with numerical
digital display on the outfeed and translation
in relation to the diameter of the positioned tool
(max. dia. of the tool 260 mm.)
- Safety guard
- Guard for working on the spindle
- Suction dust hood dia. 120 mm.
- Aluminium tables on the fence
- Height numeric read-out
- Shaft fitted to 2 coupled and
preloaded high speed bearings
- 'CE' standards
